10pcs/Lot Wired Chip 30cm 3V Railway Model toys Scenes 0402 0603 0805 1206 SMD Lamp Wired Micro Led Pre-soldered lamp model kit

10pcs/Lot Wired Chip 30cm 3V Railway Model toys Scenes 0402 0603 0805 1206 SMD Lamp Wired Micro Led Pre-soldered lamp model kit

★ Spar ekstra 15 % med: ★  10 avslag Copy
$2.48 USD
$2.48 USD
Sale Sold out
color
  • Fraktmetode: Internasjonal ekspressposttjeneste
  • Leveringstid: Standard (5–10 virkedager), Langsom (10–20 virkedager)
  • Retur: 7 dagers pengene-tilbake-garanti

SKU:12000040782237483

View full details
  • Beskrivelse
¡ñMade of high quality material,durable.
¡ñSize: SMD Led 0402 0603 0805 1206
¡ñColor:blue.yellow.red.white.warm white.green
¡ñLight Size: Approx0402 10x0.5x0.4mm/0.03x0.019x0.015inch 0603 1.6x0.8x0.6mm/0.06x0.03x0.02inch 0805 2.0x1.2x0.8mm/0.07x0.04x0.03inch 1206 3.2x1.6x0.8mm/0.12x0.06x0.03inch
¡ñWire Length:Approx.20cm
¡ñForward voltage: 2.8V~3.4V, AC or D.C compatible
¡ñForward current (typ/max): 15mA/20mA
¡ñThe Cathode is black and the Anode is red. 0402 the Cathode is Gold and the Anode is red.
¡ñ0402 wire diameter 0.1mm enameled wire 0603/0805/1206 0.34mm red and black wire
¡ñPackage Includes: 10 Pieces Model Wired LED Lights Note:This link,only including smd led lamp;if need other product,check from our store,or contact our customer service.Hope you can enjoy your shopping here. Follow us,We will send gift for you.Make sure to contact our customer service when payment done.
